Operational Amplifiers, High Slew Rate, Low Voltage, Rail-to-Rail Output

The NCS2003 family of op amps features high slew rate, low voltage operation with rail−to−rail output drive capability. The 1.8 V operation allows high performance operation in low voltage, low power applications. The fast slew rate and wide unity−gain bandwidth (5 MHz at 1.8 V) make these op amps suited for high speed applications. The low input offset voltage (4 mV max) allows the op amp to be used for current shunt monitoring. Additional features include no output phase reversal with overdriven inputs and ultra low input bias current of 1 pA.

Features

• Unity Gain Bandwidth: 7 MHz at VS = 5 V
• Fast Slew Rate: 8 V/μs rising, 12.5 V/s falling at VS = 5 V
• Rail−to−Rail Output
• No Output Phase Reversal for Over−Driven Input Signals
• Low Offset Voltage: 0.5 mV typical
• Low Input Bias Current: 1 pA typical
• NCV Prefix for Automotive and Other Applications Requiring
Unique Site and Control Change Requirements; AEC−Q100
Qualified and PPAP Capable
• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
Compliant

Applications

• Current Shunt Monitor
• Signal Conditioning
• Active Filter
• Sensor Buffer
