1.5 A, Very Low-Dropout (VLDO) Fast Transient Response Regulator Series

The NCP59150 series are high precision, very low dropout (VLDO), low ground current positive voltage regulators that are capable of providing an output current in excess of 1.5 A with a typical dropout voltage lower than 300 mV at 1.5 A load current. The devices are stable with ceramic output capacitors. This series consists of Adjustable output voltage and fixed voltage versions.

Features

• Output Current in Excess of 1.5 A
• 300 mV Typical Dropout Voltage at 1.5 A
• Adjustable and Fixed Output Voltage Options
• Low Ground Current
• Fast Transient Response
• Stable with Ceramic Output Capacitor
• Logic Compatible Enable and Error Flag Pins
• Current Limit, Reverse Current and Thermal Shutdown Protection
• Operation up to 13.5 V Input Voltage
• NCV Prefix for Automotive and Other Applications Requiring
Unique Site and Control Change Requirements; AEC−Q100
Qualified and PPAP Capable
• These are Pb−Free Devices

Applications

• Consumer and Industrial Equipment Point of Regulation
• Servers and Networking Equipment
• FPGA, DSP and Logic Power Supplies
• Switching Power Supply Post Regulation
• Battery Chargers
• Functional Replacement for Industry Standard MIC29150, MIC39150, MIC37150
